対応被削材表（◎は最適、○は適） ★ご注文は型番をクリックして ください
 |
|
| 型番 | 先端径 | テーパ半角 | コーナ半径 | 刃長 | 大端径 | 全長 | シャンク径 | 定価 | 特別価格 |
| C-CRE 2010-03-20 | 1 | 10° | 0.3 | 2 | 1.71 | 38 | 3 | 13,400 | 8,040 |
| C-CRE 2015-03-14 | 1.5 | 7° | 0.3 | 3.5 | 2.36 | 38 | 3 | 13,400 | 8,040 |
| C-CRE 2020-03-14 | 2 | 7° | 0.3 | 5 | 3.23 | 45 | 4 | 13,400 | 8,040 |
| C-CRE 2020-03-20 | 2 | 10° | 0.3 | 5 | 3.76 | 45 | 4 | 13,400 | 8,040 |
| C-CRE 2020-03-24 | 2 | 12° | 0.3 | 5 | 4.13 | 45 | 6 | 14,390 | 8,634 |
| C-CRE 2020-03-30 | 2 | 15° | 0.3 | 5 | 4.68 | 50 | 6 | 15,230 | 9,138 |
| C-CRE 2025-05-14 | 2.5 | 7° | 0.5 | 6 | 3.97 | 45 | 6 | 14,070 | 8,442 |
| C-CRE 2025-05-20 | 2.5 | 10° | 0.5 | 6 | 4.62 | 50 | 6 | 15,230 | 9,138 |
| C-CRE 2025-05-24 | 2.5 | 12° | 0.5 | 6 | 5.05 | 50 | 6 | 16,280 | 9,768 |
| C-CRE 2025-05-30 | 2.5 | 15° | 0.5 | 6 | 5.72 | 50 | 6 | 15,230 | 9,138 |
| C-CRE 2030-05-14 | 3 | 7° | 0.5 | 7 | 4.72 | 50 | 6 | 14,390 | 8,634 |
| C-CRE 2030-05-20 | 3 | 10° | 0.5 | 7 | 5.47 | 50 | 6 | 15,230 | 9,138 |
| C-CRE 2030-05-24 | 3 | 12° | 0.5 | 7 | 5.98 | 60 | 8 | 17,050 | 10,230 |
| C-CRE 2030-05-30 | 3 | 15° | 0.5 | 7 | 6.75 | 60 | 8 | 18,150 | 10,890 |
| C-CRE 2030-10-14 | 3 | 7° | 1 | 7 | 4.72 | 50 | 6 | 14,700 | 8,820 |
| C-CRE 2030-10-20 | 3 | 10° | 1 | 7 | 5.47 | 50 | 6 | 15,750 | 9,450 |
| C-CRE 2030-10-24 | 3 | 12° | 1 | 7 | 5.98 | 60 | 8 | 17,600 | 10,560 |
| C-CRE 2030-10-30 | 3 | 15° | 1 | 7 | 6.75 | 60 | 8 | 18,700 | 11,220 |
| C-CRE 2035-05-14 | 3.5 | 7° | 0.5 | 7 | 5.22 | 50 | 6 | 14,390 | 8,634 |
| C-CRE 2035-05-20 | 3.5 | 10° | 0.5 | 7 | 5.97 | 60 | 8 | 15,950 | 9,570 |
| C-CRE 2035-05-24 | 3.5 | 12° | 0.5 | 7 | 6.48 | 60 | 8 | 22,880 | 13,728 |
| C-CRE 2035-05-30 | 3.5 | 15° | 0.5 | 7 | 7.25 | 60 | 8 | 23,650 | 14,190 |
| C-CRE 2035-10-14 | 3.5 | 7° | 1 | 7 | 5.22 | 50 | 6 | 14,700 | 8,820 |
| C-CRE 2035-10-20 | 3.5 | 10° | 1 | 7 | 5.97 | 60 | 8 | 16,500 | 9,900 |
| C-CRE 2035-10-24 | 3.5 | 12° | 1 | 7 | 6.48 | 60 | 8 | 23,100 | 13,860 |
| C-CRE 2035-10-30 | 3.5 | 15° | 1 | 7 | 7.25 | 60 | 8 | 24,200 | 14,520 |
| C-CRE 2040-05-14 | 4 | 7° | 0.5 | 8 | 5.96 | 60 | 8 | 15,070 | 9,042 |
| C-CRE 2040-05-20 | 4 | 10° | 0.5 | 8 | 6.82 | 60 | 8 | 22,880 | 13,728 |
| C-CRE 2040-05-24 | 4 | 12° | 0.5 | 8 | 7.4 | 60 | 8 | 22,880 | 13,728 |
| C-CRE 2040-05-30 | 4 | 15° | 0.5 | 8 | 8.29 | 60 | 10 | 37,950 | 22,770 |
| C-CRE 2040-10-14 | 4 | 7° | 1 | 8 | 5.96 | 60 | 8 | 15,400 | 9,240 |
| C-CRE 2040-10-20 | 4 | 10° | 1 | 8 | 6.82 | 60 | 8 | 23,100 | 13,860 |
| C-CRE 2040-10-24 | 4 | 12° | 1 | 8 | 7.4 | 60 | 8 | 23,100 | 13,860 |
| C-CRE 2040-10-30 | 4 | 15° | 1 | 8 | 8.29 | 60 | 10 | 38,500 | 23,100 |
| C-CRE 2045-05-14 | 4.5 | 7° | 0.5 | 9 | 6.71 | 60 | 8 | 21,450 | 12,870 |
| C-CRE 2045-05-20 | 4.5 | 10° | 0.5 | 9 | 7.67 | 60 | 8 | 22,880 | 13,728 |
| C-CRE 2045-05-24 | 4.5 | 12° | 0.5 | 9 | 8.33 | 60 | 10 | 22,880 | 13,728 |
| C-CRE 2045-05-30 | 4.5 | 15° | 0.5 | 9 | 9.32 | 70 | 10 | 39,050 | 23,430 |
| C-CRE 2045-10-14 | 4.5 | 7° | 1 | 9 | 6.71 | 60 | 8 | 22,000 | 13,200 |
| C-CRE 2045-10-20 | 4.5 | 10° | 1 | 9 | 7.67 | 60 | 8 | 23,100 | 13,860 |
| C-CRE 2045-10-24 | 4.5 | 12° | 1 | 9 | 8.33 | 60 | 10 | 23,100 | 13,860 |
| C-CRE 2045-10-30 | 4.5 | 15° | 1 | 9 | 9.32 | 70 | 10 | 39,600 | 23,760 |
| C-CRE 2050-10-14 | 5 | 7° | 1 | 10 | 7.46 | 60 | 8 | 23,100 | 13,860 |
| C-CRE 2050-10-20 | 5 | 10° | 1 | 10 | 8.53 | 70 | 10 | 35,200 | 21,120 |
| C-CRE 2050-10-24 | 5 | 12° | 1 | 10 | 9.25 | 70 | 10 | 37,400 | 22,440 |
| C-CRE 2050-10-30 | 5 | 15° | 1 | 10 | 10.36 | 75 | 12 | 39,600 | 23,760 |
| C-CRE 2050-15-14 | 5 | 7° | 1.5 | 10 | 7.46 | 60 | 8 | 23,650 | 14,190 |
| C-CRE 2050-15-20 | 5 | 10° | 1.5 | 10 | 8.53 | 70 | 10 | 35,750 | 21,450 |
| C-CRE 2050-15-24 | 5 | 12° | 1.5 | 10 | 9.25 | 70 | 10 | 37,950 | 22,770 |
| C-CRE 2050-15-30 | 5 | 15° | 1.5 | 10 | 10.36 | 75 | 12 | 40,150 | 24,090 |
| C-CRE 2060-10-14 | 6 | 7° | 1 | 12 | 8.95 | 70 | 10 | 34,100 | 20,460 |
| C-CRE 2060-10-20 | 6 | 10° | 1 | 12 | 10.23 | 75 | 12 | 37,400 | 22,440 |
| C-CRE 2060-10-24 | 6 | 12° | 1 | 12 | 11.1 | 75 | 12 | 39,600 | 23,760 |
| C-CRE 2060-10-30 | 6 | 15° | 1 | 12 | 12.43 | 70 | 12 | 44,000 | 26,400 |
| C-CRE 2060-20-14 | 6 | 7° | 2 | 12 | 8.95 | 70 | 10 | 34,650 | 20,790 |
| C-CRE 2060-20-20 | 6 | 10° | 2 | 12 | 10.23 | 75 | 12 | 37,950 | 22,770 |
| C-CRE 2060-20-24 | 6 | 12° | 2 | 12 | 11.1 | 75 | 12 | 40,150 | 24,090 |
| C-CRE 2060-20-30 | 6 | 15° | 2 | 12 | 12.43 | 70 | 12 | 44,550 | 26,730 |
