対応被削材表（◎は最適、○は適） 　　　　　　　　　　　　　 　★ご注文は型番をクリックして ください
型番 先端径 テーパ半角 刃長 大端径 全長 シャンク径 定価 特別価格
φD A R φ D' L φd
C-CTR 4005-4-1 0.5 30′ 4 0.57 38 3 9,360 5,616
C-CTR 4005-6-1 0.5 30′ 6 0.6 38 3 9,360 5,616
C-CTR 4005-4-1.5 0.5 45′ 4 0.6 38 3 9,360 5,616
C-CTR 4005-6-1.5 0.5 45′ 6 0.66 38 3 9,360 5,616
C-CTR 4005-4-2 0.5 1° 4 0.64 38 3 9,360 5,616
C-CTR 4005-6-2 0.5 1° 6 0.71 38 3 9,360 5,616
C-CTR 4005-4-3 0.5 1°30′ 4 0.71 38 3 9,360 5,616
C-CTR 4005-6-3 0.5 1°30′ 6 0.81 38 3 9,360 5,616
C-CTR 4005-4-4 0.5 2° 4 0.78 38 3 9,360 5,616
C-CTR 4005-6-4 0.5 2° 6 0.92 38 3 9,360 5,616
C-CTR 4005-4-6 0.5 3° 4 0.92 38 3 9,360 5,616
C-CTR 4006-4-1 0.6 30′ 4 0.67 38 3 9,360 5,616
C-CTR 4006-6-1 0.6 30′ 6 0.7 38 3 9,360 5,616
C-CTR 4006-4-1.5 0.6 45′ 4 0.7 38 3 9,360 5,616
C-CTR 4006-6-1.5 0.6 45′ 6 0.76 38 3 9,360 5,616
C-CTR 4006-4-2 0.6 1° 4 0.74 38 3 9,360 5,616
C-CTR 4006-6-2 0.6 1° 6 0.81 38 3 9,360 5,616
C-CTR 4006-4-3 0.6 1°30′ 4 0.81 38 3 9,360 5,616
C-CTR 4006-6-3 0.6 1°30′ 6 0.91 38 3 9,360 5,616
C-CTR 4006-4-4 0.6 2° 4 0.88 38 3 9,360 5,616
C-CTR 4006-6-4 0.6 2° 6 1.02 38 3 9,360 5,616
C-CTR 4006-4-6 0.6 3° 4 1.02 38 3 9,360 5,616
C-CTR 4007-4-1 0.7 30′ 4 0.77 38 3 10,700 6,420
C-CTR 4007-6-1 0.7 30′ 6 0.8 38 3 10,700 6,420
C-CTR 4007-8-1 0.7 30′ 8 0.84 38 3 10,700 6,420
C-CTR 4007-6-1.5 0.7 45′ 6 0.86 38 3 10,700 6,420
C-CTR 4007-8-1.5 0.7 45′ 8 0.91 38 3 10,700 6,420
C-CTR 4007-4-2 0.7 1° 4 0.84 38 3 10,700 6,420
C-CTR 4007-6-2 0.7 1° 6 0.91 38 3 10,700 6,420
C-CTR 4007-8-2 0.7 1° 8 0.98 38 3 10,700 6,420
C-CTR 4007-4-3 0.7 1 °30′ 4 0.91 38 3 10,700 6,420
C-CTR 4007-6-3 0.7 1 °30′ 6 1.01 38 3 10,700 6,420
C-CTR 4007-8-3 0.7 1 °30′ 8 1.12 38 3 10,700 6,420
C-CTR 4007-4-4 0.7 2° 4 0.98 38 3 10,700 6,420
C-CTR 4007-6-4 0.7 2° 6 1.12 38 3 10,700 6,420
C-CTR 4007-8-4 0.7 2° 8 1.26 38 3 10,700 6,420
C-CTR 4007-6-6 0.7 3° 6 1.33 38 3 10,700 6,420
C-CTR 4008-6-1 0.8 30′ 6 0.9 38 3 9,360 5,616
C-CTR 4008-8-1 0.8 30′ 8 0.94 38 3 9,360 5,616
C-CTR 4008-10-1 0.8 30′ 10 0.97 45 4 9,360 5,616
C-CTR 4008-6-1.5 0.8 45′ 6 0.96 38 3 9,360 5,616
C-CTR 4008-8-1.5 0.8 45′ 8 1.01 38 3 9,360 5,616
C-CTR 4008-10-1.5 0.8 45′ 10 1.06 45 4 9,360 5,616
C-CTR 4008-6-2 0.8 1° 6 1.01 38 3 9,360 5,616
C-CTR 4008-8-2 0.8 1° 8 1.08 38 3 9,360 5,616
C-CTR 4008-10-2 0.8 1° 10 1.15 45 4 9,360 5,616
C-CTR 4008-6-3 0.8 1 °30′ 6 1.11 38 3 9,360 5,616
C-CTR 4008-8-3 0.8 1 °30′ 8 1.22 38 3 9,360 5,616
C-CTR 4008-10-3 0.8 1 °30′ 10 1.32 45 4 9,360 5,616
C-CTR 4008-6-4 0.8 2° 6 1.22 38 3 9,360 5,616
C-CTR 4008-8-4 0.8 2° 8 1.36 38 3 9,360 5,616
C-CTR 4008-10-4 0.8 2° 10 1.5 45 4 9,360 5,616
C-CTR 4008-6-6 0.8 3° 6 1.43 38 3 9,360 5,616
C-CTR 4008-10-6 0.8 3° 10 1.85 45 4 9,360 5,616
C-CTR 4009-6-1 0.9 30′ 6 1 38 3 10,700 6,420
C-CTR 4009-8-1 0.9 30′ 8 1.04 38 3 10,700 6,420
C-CTR 4009-10-1 0.9 30′ 10 1.07 45 4 10,700 6,420
C-CTR 4009-6-1.5 0.9 45′ 6 1.06 38 3 10,700 6,420
C-CTR 4009-8-1.5 0.9 45′ 8 1.11 38 3 10,700 6,420
C-CTR 4009-10-1.5 0.9 45′ 10 1.16 45 4 10,700 6,420
C-CTR 4009-6-2 0.9 1° 6 1.11 38 3 10,700 6,420
C-CTR 4009-8-2 0.9 1° 8 1.18 38 3 10,700 6,420
C-CTR 4009-10-2 0.9 1° 10 1.25 45 4 10,700 6,420
C-CTR 4009-6-3 0.9 1°30′ 6 1.21 38 3 10,700 6,420
C-CTR 4009-8-3 0.9 1°30′ 8 1.32 38 3 10,700 6,420
C-CTR 4009-10-3 0.9 1°30′ 10 1.42 45 4 10,700 6,420
C-CTR 4009-6-4 0.9 2° 6 1.32 38 3 10,700 6,420
C-CTR 4009-8-4 0.9 2° 8 1.46 38 3 10,700 6,420
C-CTR 4009-10-4 0.9 2° 10 1.6 45 4 10,700 6,420
C-CTR 4009-8-6 0.9 3° 8 1.74 38 3 10,700 6,420
C-CTR 4010-8-1 1 30′ 8 1.14 45 4 9,360 5,616
C-CTR 4010-10-1 1 30′ 10 1.17 45 4 9,360 5,616
C-CTR 4010-12-1 1 30′ 12 1.21 45 4 9,600 5,760
C-CTR 4010-16-1 1 30′ 16 1.28 50 4 9,600 5,760
C-CTR 4010-20-1 1 30′ 20 1.35 55 4 9,600 5,760
C-CTR 4010-8-1.5 1 45′ 8 1.21 45 4 9,360 5,616
C-CTR 4010-10-1.5 1 45′ 10 1.26 45 4 9,360 5,616
C-CTR 4010-12-1.5 1 45′ 12 1.31 45 4 9,600 5,760
C-CTR 4010-8-2 1 1° 8 1.28 45 4 9,360 5,616
C-CTR 4010-10-2 1 1° 10 1.35 45 4 9,360 5,616
C-CTR 4010-12-2 1 1° 12 1.42 45 4 9,600 5,760
C-CTR 4010-16-2 1 1° 16 1.56 50 4 9,600 5,760
C-CTR 4010-20-2 1 1° 20 1.7 55 4 9,600 5,760
C-CTR 4010-8-3 1 1°30′ 8 1.42 45 4 9,360 5,616
C-CTR 4010-10-3 1 1°30′ 10 1.52 45 4 9,360 5,616
C-CTR 4010-12-3 1 1°30′ 12 1.63 45 4 9,600 5,760
C-CTR 4010-16-3 1 1°30′ 16 1.84 50 4 9,600 5,760
C-CTR 4010-20-3 1 1°30′ 20 2.05 55 4 9,600 5,760
C-CTR 4010-8-4 1 2° 8 1.56 45 4 9,360 5,616
C-CTR 4010-10-4 1 2° 10 1.7 45 4 9,360 5,616
C-CTR 4010-12-4 1 2° 12 1.84 45 4 9,600 5,760
C-CTR 4010-16-4 1 2° 16 2.12 50 4 9,600 5,760
C-CTR 4010-20-4 1 2° 20 2.4 55 4 9,600 5,760
C-CTR 4010-8-6 1 3° 8 1.84 45 4 9,360 5,616
C-CTR 4010-12-6 1 3° 12 2.26 45 4 9,600 5,760
C-CTR 4010-16-6 1 3° 16 2.68 50 4 9,600 5,760
C-CTR 4010-20-6 1 3° 20 3.09 55 4 9,600 5,760
C-CTR 4011-8-1 1.1 30′ 8 1.24 45 4 11,700 7,020
C-CTR 4011-12-1 1.1 30′ 12 1.31 45 4 11,900 7,140
C-CTR 4011-8-2 1.1 1° 8 1.38 45 4 11,700 7,020
C-CTR 4011-12-2 1.1 1° 12 1.52 45 4 11,900 7,140
C-CTR 4011-8-3 1.1 1°30′ 8 1.52 45 4 11,700 7,020
C-CTR 4011-12-3 1.1 1°30′ 12 1.73 45 4 11,900 7,140
C-CTR 4011-8-4 1.1 2° 8 1.66 45 4 11,700 7,020
C-CTR 4011-12-4 1.1 2° 12 1.94 45 4 11,900 7,140
C-CTR 4012-8-1 1.2 30′ 8 1.34 45 4 10,700 6,420
C-CTR 4012-10-1 1.2 30′ 10 1.37 45 4 10,700 6,420
C-CTR 4012-12-1 1.2 30′ 12 1.41 45 4 10,900 6,540
C-CTR 4012-16-1 1.2 30′ 16 1.48 55 4 11,100 6,660
C-CTR 4012-20-1 1.2 30′ 20 1.55 55 4 13,000 7,800
C-CTR 4012-8-1.5 1.2 45′ 8 1.41 45 4 10,700 6,420
C-CTR 4012-10-1.5 1.2 45′ 10 1.46 45 4 10,700 6,420
C-CTR 4012-12-1.5 1.2 45′ 12 1.51 45 4 10,900 6,540
C-CTR 4012-16-1.5 1.2 45′ 16 1.62 55 4 11,100 6,660
C-CTR 4012-8-2 1.2 1° 8 1.48 45 4 10,700 6,420
C-CTR 4012-10-2 1.2 1° 10 1.55 45 4 10,700 6,420
C-CTR 4012-12-2 1.2 1° 12 1.62 45 4 10,900 6,540
C-CTR 4012-16-2 1.2 1° 16 1.76 55 4 11,100 6,660
C-CTR 4012-20-2 1.2 1° 20 1.9 55 4 13,000 7,800
C-CTR 4012-8-3 1.2 1°30′ 8 1.62 45 4 10,700 6,420
C-CTR 4012-10-3 1.2 1°30′ 10 1.72 45 4 10,700 6,420
C-CTR 4012-12-3 1.2 1°30′ 12 1.83 45 4 10,900 6,540
C-CTR 4012-16-3 1.2 1°30′ 16 2.04 55 4 11,100 6,660
C-CTR 4012-20-3 1.2 1°30′ 20 2.25 55 4 13,000 7,800
C-CTR 4012-8-4 1.2 2° 8 1.76 45 4 10,700 6,420
C-CTR 4012-10-4 1.2 2° 10 1.9 45 4 10,700 6,420
C-CTR 4012-12-4 1.2 2° 1 2 2.04 45 4 10,900 6,540
C-CTR 4012-16-4 1.2 2° 16 2.32 55 4 11,100 6,660
C-CTR 4012-20-4 1.2 2° 20 2.6 55 4 13,000 7,800
C-CTR 4012-10-6 1.2 3° 10 2.25 45 4 10,700 6,420
C-CTR 4012-16-6 1.2 3° 1 6 2.88 45 4 11,100 6,660
C-CTR 4012-20-6 1.2 3° 20 3.29 55 4 13,000 7,800
C-CTR 4013-8-1 1.3 30 ′ 8 1.44 45 4 11,700 7,020
C-CTR 4013-12-1 1.3 30 ′ 12 1.51 45 4 11,900 7,140
C-CTR 4013-8-2 1.3 1° 8 1.58 45 4 11,700 7,020
C-CTR 4013-12-2 1.3 1° 12 1.72 45 4 11,900 7,140
C-CTR 4013-8-3 1.3 1 °30 ′ 8 1.72 45 4 11,700 7,020
C-CTR 4013-12-3 1.3 1 °30 ′ 12 1.93 45 4 11,900 7,140
C-CTR 4013-8-4 1.3 2° 8 1.86 45 4 11,700 7,020
C-CTR 4013-12-4 1.3 2° 12 2.14 45 4 11,900 7,140
C-CTR 4014-8-1 1.4 30 ′ 8 1.54 45 4 11,700 7,020
C-CTR 4014-12-1 1.4 30 ′ 1 2 1.61 45 4 11,900 7,140
C-CTR 4014-16-1 1.4 30 ′ 16 1.68 55 4 11,100 6,660
C-CTR 4014-8-2 1.4 1° 8 1.68 45 4 11,700 7,020
C-CTR 4014-12-2 1.4 1° 1 2 1.82 45 4 11,900 7,140
C-CTR 4014-16-2 1.4 1° 16 1.96 55 4 11,100 6,660
C-CTR 4014-8-3 1.4 1 °30 ′ 8 1.82 45 4 11,700 7,020
C-CTR 4014-12-3 1.4 1 °30 ′ 1 2 2.03 45 4 11,900 7,140
C-CTR 4014-16-3 1.4 1 °30 ′ 16 2.24 55 4 11,100 6,660
C-CTR 4014-8-4 1.4 2° 8 1.96 45 4 11,700 7,020
C-CTR 4014-12-4 1.4 2° 1 2 2.24 45 4 11,900 7,140
C-CTR 4014-16-4 1.4 2° 16 2.52 55 4 11,100 6,660
C-CTR 4015-8-1 1.5 30 ′ 8 1.64 45 4 10,900 6,540
C-CTR 4015-10-1 1.5 30 ′ 10 1.67 45 4 10,900 6,540
C-CTR 4015-12-1 1.5 30 ′ 1 2 1.71 45 4 10,900 6,540
C-CTR 4015-16-1 1.5 30 ′ 16 1.78 55 4 11,100 6,660
C-CTR 4015-20-1 1.5 30 ′ 20 1.85 60 4 11,800 7,080
C-CTR 4015-8-1.5 1.5 45 ′ 8 1.71 45 4 10,900 6,540
C-CTR 4015-10-1.5 1.5 45 ′ 10 1.76 45 4 10,900 6,540
C-CTR 4015-12-1.5 1.5 45 ′ 1 2 1.81 45 4 10,900 6,540
C-CTR 4015-16-1.5 1.5 45 ′ 16 1.92 55 4 11,100 6,660
C-CTR 4015-20-1.5 1.5 45 ′ 20 2.02 60 4 11,800 7,080
C-CTR 4015-8-2 1.5 1° 8 1.78 45 4 10,900 6,540
C-CTR 4015-10-2 1.5 1° 10 1.85 45 4 10,900 6,540
C-CTR 4015-12-2 1.5 1° 12 1.92 45 4 10,900 6,540
C-CTR 4015-16-2 1.5 1° 16 2.06 55 4 11,100 6,660
C-CTR 4015-20-2 1.5 1° 20 2.2 60 4 11,800 7,080
C-CTR 4015-8-3 1.5 1°30′ 8 1.92 45 4 10,900 6,540
C-CTR 4015-10-3 1.5 1°30′ 10 2.02 45 4 10,900 6,540
C-CTR 4015-12-3 1.5 1°30′ 12 2.13 45 4 10,900 6,540
C-CTR 4015-16-3 1.5 1°30′ 16 2.34 55 4 11,100 6,660
C-CTR 4015-20-3 1.5 1°30′ 20 2.55 60 4 11,800 7,080
C-CTR 4015-8-4 1.5 2° 8 2.06 45 4 10,900 6,540
C-CTR 4015-10-4 1.5 2° 10 2.2 45 4 10,900 6,540
C-CTR 4015-12-4 1.5 2° 12 2.34 45 4 10,900 6,540
C-CTR 4015-16-4 1.5 2° 16 2.62 55 4 11,100 6,660
C-CTR 4015-20-4 1.5 2° 20 2.9 60 4 11,800 7,080
C-CTR 4015-12-6 1.5 3° 12 2.76 45 4 10,900 6,540
C-CTR 4015-20-6 1.5 3° 20 3.6 60 6 12,390 7,434
C-CTR 4016-8-1 1.6 30′ 8 1.74 45 4 10,900 6,540
C-CTR 4016-10-1 1.6 30′ 10 1.77 45 4 11,100 6,660
C-CTR 4016-12-1 1.6 30′ 12 1.81 45 4 11,100 6,660
C-CTR 4016-16-1 1.6 30′ 16 1.88 55 4 11,100 6,660
C-CTR 4016-20-1 1.6 30′ 20 1.95 60 4 11,800 7,080
C-CTR 4016-8-1.5 1.6 45′ 8 1.81 45 4 10,900 6,540
C-CTR 4016-10-1.5 1.6 45′ 10 1.86 45 4 11,100 6,660
C-CTR 4016-12-1.5 1.6 45′ 12 1.91 45 4 11,100 6,660
C-CTR 4016-16-1.5 1.6 45′ 16 2.02 55 4 11,100 6,660
C-CTR 4016-20-1.5 1.6 45′ 20 2.12 60 4 11,800 7,080
C-CTR 4016-8-2 1.6 1° 8 1.88 45 4 10,900 6,540
C-CTR 4016-10-2 1.6 1° 10 1.95 45 4 11,100 6,660
C-CTR 4016-12-2 1.6 1° 12 2.02 45 4 11,100 6,660
C-CTR 4016-16-2 1.6 1° 16 2.16 55 4 11,100 6,660
C-CTR 4016-20-2 1.6 1° 20 2.3 60 4 11,800 7,080
C-CTR 4016-8-3 1.6 1°30′ 8 2.02 45 4 10,900 6,540
C-CTR 4016-10-3 1.6 1°30′ 10 2.12 45 4 11,100 6,660
C-CTR 4016-12-3 1.6 1°30′ 12 2.23 45 4 11,100 6,660
C-CTR 4016-16-3 1.6 1°30′ 16 2.44 55 4 11,100 6,660
C-CTR 4016-20-3 1.6 1°30′ 20 2.65 60 4 11,800 7,080
C-CTR 4016-8-4 1.6 2° 8 2.16 45 4 10,900 6,540
C-CTR 4016-10-4 1.6 2° 10 2.3 45 4 11,100 6,660
C-CTR 4016-12-4 1.6 2° 12 2.44 45 4 11,100 6,660
C-CTR 4016-16-4 1.6 2° 16 2.72 55 4 11,100 6,660
C-CTR 4016-20-4 1.6 2° 20 3 60 4 11,800 7,080
C-CTR 4016-12-6 1.6 3° 12 2.86 45 4 11,100 6,660
C-CTR 4016-20-6 1.6 3° 20 3.7 60 6 12,390 7,434
C-CTR 4017-8-1 1.7 30′ 8 1.84 45 4 11,900 7,140
C-CTR 4017-12-1 1.7 30′ 12 1.91 45 4 12,100 7,260
C-CTR 4017-16-1 1.7 30′ 16 1.98 55 4 12,100 7,260
C-CTR 4017-20-1 1.7 30′ 20 2.05 60 4 12,800 7,680
C-CTR 4017-8-2 1.7 1° 8 1.98 45 4 11,900 7,140
C-CTR 4017-12-2 1.7 1° 12 2.12 45 4 12,100 7,260
C-CTR 4017-16-2 1.7 1° 16 2.26 55 4 12,100 7,260
C-CTR 4017-20-2 1.7 1° 20 2.4 60 4 12,800 7,680
C-CTR 4017-8-3 1.7 1°30′ 8 2.12 45 4 11,900 7,140
C-CTR 4017-12-3 1.7 1°30′ 12 2.33 45 4 12,100 7,260
C-CTR 4017-16-3 1.7 1°30′ 16 2.54 55 4 12,100 7,260
C-CTR 4017-20-3 1.7 1°30′ 20 2.75 60 4 12,800 7,680
C-CTR 4017-8-4 1.7 2° 8 2.26 45 4 11,900 7,140
C-CTR 4017-12-4 1.7 2° 12 2.54 45 4 12,100 7,260
C-CTR 4017-16-4 1.7 2° 16 2.82 55 4 12,100 7,260
C-CTR 4017-20-4 1.7 2° 20 3.1 60 4 12,800 7,680
C-CTR 4018-8-1 1.8 30′ 8 1.94 45 4 10,900 6,540
C-CTR 4018-10-1 1.8 30′ 10 1.97 45 4 11,100 6,660
C-CTR 4018-12-1 1.8 30′ 12 2.01 45 4 11,100 6,660
C-CTR 4018-16-1 1.8 30′ 16 2.08 55 4 11,100 6,660
C-CTR 4018-20-1 1.8 30′ 20 2.15 60 4 11,800 7,080
C-CTR 4018-8-1.5 1.8 45′ 8 2.01 45 4 10,900 6,540
C-CTR 4018-10-1.5 1.8 45′ 10 2.06 45 4 11,100 6,660
C-CTR 4018-12-1.5 1.8 45′ 12 2.11 45 4 11,100 6,660
C-CTR 4018-16-1.5 1.8 45′ 16 2.22 55 4 11,100 6,660
C-CTR 4018-20-1.5 1.8 45′ 20 2.32 60 4 11,800 7,080
C-CTR 4018-8-2 1.8 1° 8 2.08 45 4 10,900 6,540
C-CTR 4018-10-2 1.8 1° 10 2.15 45 4 11,100 6,660
C-CTR 4018-12-2 1.8 1° 12 2.22 45 4 11,100 6,660
C-CTR 4018-16-2 1.8 1° 16 2.36 55 4 11,100 6,660
C-CTR 4018-20-2 1.8 1° 20 2.5 60 4 11,800 7,080
C-CTR 4018-8-3 1.8 1°30′ 8 2.22 45 4 10,900 6,540
C-CTR 4018-10-3 1.8 1°30′ 10 2.32 45 4 11,100 6,660
C-CTR 4018-12-3 1.8 1°30′ 12 2.43 45 4 11,100 6,660
C-CTR 4018-16-3 1.8 1°30′ 16 2.64 55 4 11,100 6,660
C-CTR 4018-20-3 1.8 1°30′ 20 2.85 60 4 11,800 7,080
C-CTR 4018-8-4 1.8 2° 8 2.36 45 4 10,900 6,540
C-CTR 4018-10-4 1.8 2° 10 2.5 45 4 11,100 6,660
C-CTR 4018-12-4 1.8 2° 12 2.64 45 4 11,100 6,660
C-CTR 4018-16-4 1.8 2° 16 2.92 55 4 11,100 6,660
C-CTR 4018-20-4 1.8 2° 20 3.2 60 4 11,800 7,080
C-CTR 4018-12-6 1.8 3° 12 3.06 45 4 11,100 6,660
C-CTR 4018-20-6 1.8 3° 20 3.9 60 6 12,390 7,434
C-CTR 4019-8-1 1.9 30′ 8 2.04 45 4 11,900 7,140
C-CTR 4019-12-1 1.9 30′ 12 2.11 45 4 12,100 7,260
C-CTR 4019-16-1 1.9 30′ 16 2.18 55 4 12,100 7,260
C-CTR 4019-20-1 1.9 30′ 20 2.25 60 4 12,800 7,680
C-CTR 4019-8-2 1.9 1° 8 2.18 45 4 11,900 7,140
C-CTR 4019-12-2 1.9 1° 12 2.32 45 4 12,100 7,260
C-CTR 4019-16-2 1.9 1° 16 2.46 55 4 12,100 7,260
C-CTR 4019-20-2 1.9 1° 20 2.6 60 4 12,800 7,680
C-CTR 4019-8-3 1.9 1°30′ 8 2.32 45 4 11,900 7,140
C-CTR 4019-12-3 1.9 1°30′ 12 2.53 45 4 12,100 7,260
C-CTR 4019-16-3 1.9 1°30′ 16 2.74 55 4 12,100 7,260
C-CTR 4019-20-3 1.9 1°30′ 20 2.95 60 4 12,800 7,680
C-CTR 4019-8-4 1.9 2° 8 2.46 45 4 11,900 7,140
C-CTR 4019-12-4 1.9 2° 12 2.74 45 4 12,100 7,260
C-CTR 4019-16-4 1.9 2° 16 3.02 55 4 12,100 7,260
C-CTR 4019-20-4 1.9 2° 20 3.3 60 4 12,800 7,680
C-CTR 4020-8-1 2 30′ 8 2.14 45 4 10,900 6,540
C-CTR 4020-10-1 2 30′ 10 2.17 45 4 11,800 7,080
C-CTR 4020-12-1 2 30′ 12 2.21 45 4 11,800 7,080
C-CTR 4020-16-1 2 30′ 16 2.28 55 4 11,800 7,080
C-CTR 4020-20-1 2 30′ 20 2.35 60 4 11,800 7,080
C-CTR 4020-25-1 2 30′ 25 2.44 60 4 12,600 7,560
C-CTR 4020-10-1.5 2 45′ 10 2.26 45 4 11,800 7,080
C-CTR 4020-12-1.5 2 45′ 12 2.31 45 4 11,800 7,080
C-CTR 4020-16-1.5 2 45′ 1 6 2.42 55 4 11,800 7,080
C-CTR 4020-20-1.5 2 45′ 20 2.52 60 4 11,800 7,080
C-CTR 4020-25-1.5 2 45′ 25 2.65 60 4 12,600 7,560
C-CTR 4020-8-2 2 1° 8 2.28 45 4 10,900 6,540
C-CTR 4020-10-2 2 1° 1 0 2.35 45 4 11,800 7,080
C-CTR 4020-12-2 2 1° 12 2.42 45 4 11,800 7,080
C-CTR 4020-16-2 2 1° 16 2.56 55 4 11,800 7,080
C-CTR 4020-20-2 2 1° 2 0 2.7 60 4 11,800 7,080
C-CTR 4020-25-2 2 1° 25 2.87 60 4 12,600 7,560
C-CTR 4020-8-3 2 1°30′ 8 2.42 45 4 10,900 6,540
C-CTR 4020-10-3 2 1°30′ 10 2.52 45 4 11,800 7,080
C-CTR 4020-12-3 2 1°30′ 12 2.63 45 4 11,800 7,080
C-CTR 4020-16-3 2 1°30′ 16 2.84 55 4 11,800 7,080
C-CTR 4020-20-3 2 1°30′ 20 3.05 60 4 11,800 7,080
C-CTR 4020-25-3 2 1°30′ 25 3.31 65 6 13,230 7,938
C-CTR 4020-8-4 2 2° 8 2.56 45 4 10,900 6,540
C-CTR 4020-10-4 2 2° 10 2.7 45 4 11,800 7,080
C-CTR 4020-12-4 2 2° 12 2.84 45 4 11,800 7,080
C-CTR 4020-16-4 2 2° 16 3.12 55 4 11,800 7,080
C-CTR 4020-20-4 2 2° 20 3.4 60 4 11,800 7,080
C-CTR 4020-25-4 2 2° 25 3.75 65 6 13,230 7,938
C-CTR 4020-16-6 2 3° 16 3.68 60 6 12,390 7,434
C-CTR 4020-25-6 2 3° 25 4.62 60 6 13,230 7,938
C-CTR 4025-10-1 2.5 30′ 10 2.67 55 6 13,550 8,130
C-CTR 4025-12-1 2.5 30′ 12 2.71 60 6 13,550 8,130
C-CTR 4025-16-1 2.5 30′ 16 2.78 60 6 13,550 8,130
C-CTR 4025-20-1 2.5 30′ 20 2.85 60 6 13,550 8,130
C-CTR 4025-25-1 2.5 30′ 25 2.94 70 6 13,550 8,130
C-CTR 4025-30-1 2.5 30′ 30 3.02 70 6 14,810 8,886
C-CTR 4025-10-1.5 2.5 45′ 10 2.76 55 6 13,550 8,130
C-CTR 4025-12-1.5 2.5 45′ 12 2.81 55 6 13,550 8,130
C-CTR 4025-16-1.5 2.5 45′ 16 2.92 60 6 13,550 8,130
C-CTR 4025-20-1.5 2.5 45′ 20 3.02 60 6 13,550 8,130
C-CTR 4025-25-1.5 2.5 45′ 25 3.15 70 6 13,550 8,130
C-CTR 4025-30-1.5 2.5 45′ 30 3.29 70 6 14,810 8,886
C-CTR 4025-10-2 2.5 1° 10 2.85 55 6 13,550 8,130
C-CTR 4025-12-2 2.5 1° 12 2.92 55 6 13,550 8,130
C-CTR 4025-16-2 2.5 1° 16 3.06 55 6 13,550 8,130
C-CTR 4025-20-2 2.5 1° 20 3.2 70 6 13,550 8,130
C-CTR 4025-25-2 2.5 1° 25 3.37 70 6 13,550 8,130
C-CTR 4025-30-2 2.5 1° 30 3.55 70 6 14,810 8,886
C-CTR 4025-10-3 2.5 1°30′ 10 3.02 55 6 13,550 8,130
C-CTR 4025-12-3 2.5 1°30′ 12 3.13 55 6 13,550 8,130
C-CTR 4025-16-3 2.5 1°30′ 16 3.34 60 6 13,550 8,130
C-CTR 4025-20-3 2.5 1°30′ 20 3.55 60 6 13,550 8,130
C-CTR 4025-25-3 2.5 1°30′ 25 3.81 70 6 13,550 8,130
C-CTR 4025-30-3 2.5 1°30′ 30 4.07 70 6 14,810 8,886
C-CTR 4025-10-4 2.5 2° 10 3.2 55 6 13,550 8,130
C-CTR 4025-12-4 2.5 2° 12 3.34 55 6 13,550 8,130
C-CTR 4025-16-4 2.5 2° 16 3.62 55 6 13,550 8,130
C-CTR 4025-20-4 2.5 2° 20 3.9 60 6 13,550 8,130
C-CTR 4025-25-4 2.5 2° 25 4.25 70 6 13,550 8,130
C-CTR 4025-30-4 2.5 2° 30 4.6 70 6 14,810 8,886
C-CTR 4025-20-6 2.5 3° 20 4.6 60 6 13,550 8,130
C-CTR 4025-25-6 2.5 3° 25 5.12 70 6 13,550 8,130
C-CTR 4025-30-6 2.5 3° 30 5.64 70 6 14,810 8,886
C-CTR 4030-25-1 3 30′ 25 3.44 70 6 14,810 8,886
C-CTR 4030-30-1 3 30′ 30 3.52 70 6 14,810 8,886
C-CTR 4030-25-1.5 3 45′ 25 3.65 70 6 14,810 8,886
C-CTR 4030-40-1.5 3 45′ 40 4.05 80 6 16,380 9,828
C-CTR 4030-20-2 3 1° 20 3.7 70 6 14,810 8,886
C-CTR 4030-25-2 3 1° 25 3.87 70 6 14,810 8,886
C-CTR 4030-30-2 3 1° 30 4.05 70 6 14,810 8,886
C-CTR 4030-40-2 3 1° 40 4.4 80 6 16,380 9,828
C-CTR 4030-25-3 3 1°30′ 25 4.31 65 6 14,810 8,886
C-CTR 4030-40-3 3 1°30′ 40 5.09 80 6 16,380 9,828
C-CTR 4030-25-4 3 2° 25 4.75 70 6 14,810 8,886
C-CTR 4030-30-4 3 2° 30 5.1 70 6 14,810 8,886
C-CTR 4030-40-4 3 2° 40 5.79 80 8 17,160 10,296
C-CTR 4030-25-6 3 3° 25 5.62 70 6 14,810 8,886
C-CTR 4030-40-6 3 3° 40 7.19 80 8 17,160 10,296
〒124-0025 東京都葛飾区西新小岩４丁目８−１４
株式会社　クロダ　TEL 03(3692)5620 FAX 03(5698)8117
E-Mail info@cpc-croda.co.jp
