対応被削材表（◎は最適、○は適） ★ご注文は型番をクリックして ください
 |
|
| 型番 | ボール半径 | 有効長 | 刃長 | 首径 | シャンクテーパ角 | 全長 | シャンク径 | 有効シャンク長 | 定価 | 特別価格 |
| HLB2002-003S | R0.1 | 0.3 | 0.16 | 0.17 | 16° | 40 | 4 | 30.5 | 11,420 | 6,852 |
| HLB2002-005S | R0.1 | 0.5 | 0.16 | 0.17 | 16° | 40 | 4 | 30.0 | 10,080 | 6,048 |
| HLB2002-0075S | R0.1 | 0.75 | 0.16 | 0.17 | 16° | 40 | 4 | 30.0 | 10,080 | 6,048 |
| HLB2002-010S | R0.1 | 1 | 0.16 | 0.17 | 16° | 40 | 4 | 29.5 | 10,080 | 6,048 |
| HLB2002-0125S | R0.1 | 1.25 | 0.16 | 0.17 | 16° | 40 | 4 | 29.5 | 10,920 | 6,552 |
| HLB2002-015S | R0.1 | 1.5 | 0.16 | 0.17 | 16° | 40 | 4 | 29.0 | 10,920 | 6,552 |
| HLB2002-0175S | R0.1 | 1.75 | 0.16 | 0.17 | 16° | 40 | 4 | 29.0 | 12,000 | 7,200 |
| HLB2002-020S | R0.1 | 2 | 0.16 | 0.17 | 16° | 40 | 4 | 28.5 | 12,000 | 7,200 |
| HLB2003-005S | R0.15 | 0.5 | 0.24 | 0.27 | 16° | 40 | 4 | 30.5 | 9,840 | 5,904 |
| HLB2003-006S | R0.15 | 0.6 | 0.24 | 0.27 | 16° | 40 | 4 | 30.5 | 9,840 | 5,904 |
| HLB2003-0075S | R0.15 | 0.75 | 0.24 | 0.27 | 16° | 40 | 4 | 30.0 | 9,840 | 5,904 |
| HLB2003-010S | R0.15 | 1 | 0.24 | 0.27 | 16° | 40 | 4 | 30.0 | 9,840 | 5,904 |
| HLB2003-0125S | R0.15 | 1.25 | 0.24 | 0.27 | 16° | 40 | 4 | 29.5 | 10,560 | 6,336 |
| HLB2003-015S | R0.15 | 1.5 | 0.24 | 0.27 | 16° | 40 | 4 | 29.5 | 10,560 | 6,336 |
| HLB2003-0175S | R0.15 | 1.75 | 0.24 | 0.27 | 16° | 40 | 4 | 29.0 | 10,560 | 6,336 |
| HLB2003-020S | R0.15 | 2 | 0.24 | 0.27 | 16° | 40 | 4 | 29.0 | 10,560 | 6,336 |
| HLB2003-0225S | R0.15 | 2.25 | 0.24 | 0.27 | 16° | 40 | 4 | 28.5 | 10,920 | 6,552 |
| HLB2003-025S | R0.15 | 2.5 | 0.24 | 0.27 | 16° | 40 | 4 | 28.5 | 10,920 | 6,552 |
| HLB2003-030S | R0.15 | 3 | 0.24 | 0.27 | 16° | 40 | 4 | 28.0 | 10,920 | 6,552 |
| HLB2004-0075S | R0.2 | 0.75 | 0.32 | 0.37 | 16° | 40 | 4 | 30.5 | 6,720 | 4,032 |
| HLB2004-010S | R0.2 | 1 | 0.32 | 0.37 | 16° | 40 | 4 | 30.0 | 6,720 | 4,032 |
| HLB2004-015S | R0.2 | 1.5 | 0.32 | 0.37 | 16° | 40 | 4 | 29.5 | 6,840 | 4,104 |
| HLB2004-020S | R0.2 | 2 | 0.32 | 0.37 | 16° | 40 | 4 | 29.0 | 7,080 | 4,248 |
| HLB2004-025S | R0.2 | 2.5 | 0.32 | 0.37 | 16° | 40 | 4 | 28.5 | 7,320 | 4,392 |
| HLB2004-030S | R0.2 | 3 | 0.32 | 0.37 | 16° | 40 | 4 | 28.0 | 7,800 | 4,680 |
| HLB2004-035S | R0.2 | 3.5 | 0.32 | 0.37 | 16° | 40 | 4 | 27.5 | 8,400 | 5,040 |
| HLB2004-040S | R0.2 | 4 | 0.32 | 0.37 | 16° | 40 | 4 | 27.0 | 8,400 | 5,040 |
| HLB2005-010S | R0.25 | 1 | 0.4 | 0.47 | 16° | 40 | 4 | 30.5 | 6,720 | 4,032 |
| HLB2005-015S | R0.25 | 1.5 | 0.4 | 0.47 | 16° | 40 | 4 | 30.0 | 6,720 | 4,032 |
| HLB2005-020S | R0.25 | 2 | 0.4 | 0.47 | 16° | 40 | 4 | 29.5 | 6,720 | 4,032 |
| HLB2005-025S | R0.25 | 2.5 | 0.4 | 0.47 | 16° | 40 | 4 | 29.0 | 6,720 | 4,032 |
| HLB2005-030S | R0.25 | 3 | 0.4 | 0.47 | 16° | 40 | 4 | 28.5 | 6,720 | 4,032 |
| HLB2005-035S | R0.25 | 3.5 | 0.4 | 0.47 | 16° | 40 | 4 | 28.0 | 6,720 | 4,032 |
| HLB2005-040S | R0.25 | 4 | 0.4 | 0.47 | 16° | 40 | 4 | 27.5 | 6,720 | 4,032 |
| HLB2006-015S | R0.3 | 1.5 | 0.48 | 0.57 | 16° | 40 | 4 | 30.0 | 5,160 | 3,096 |
| HLB2006-020S | R0.3 | 2 | 0.48 | 0.57 | 16° | 40 | 4 | 29.5 | 5,160 | 3,096 |
| HLB2006-025S | R0.3 | 2.5 | 0.48 | 0.57 | 16° | 40 | 4 | 29.0 | 5,280 | 3,168 |
| HLB2006-030S | R0.3 | 3 | 0.48 | 0.57 | 16° | 40 | 4 | 28.5 | 5,280 | 3,168 |
| HLB2006-035S | R0.3 | 3.5 | 0.48 | 0.57 | 16° | 40 | 4 | 28.0 | 5,520 | 3,312 |
| HLB2006-040S | R0.3 | 4 | 0.48 | 0.57 | 16° | 40 | 4 | 27.5 | 5,520 | 3,312 |
| HLB2006-045S | R0.3 | 4.5 | 0.48 | 0.57 | 16° | 40 | 4 | 27.0 | 5,520 | 3,312 |
| HLB2006-050S | R0.3 | 5 | 0.48 | 0.57 | 16° | 40 | 4 | 26.5 | 5,520 | 3,312 |
| HLB2006-055S | R0.3 | 5.5 | 0.48 | 0.57 | 16° | 40 | 4 | 26.0 | 5,520 | 3,312 |
| HLB2008-020S | R0.4 | 2 | 0.64 | 0.77 | 16° | 40 | 4 | 30.0 | 5,160 | 3,096 |
| HLB2008-030S | R0.4 | 3 | 0.64 | 0.77 | 16° | 40 | 4 | 29.0 | 5,520 | 3,312 |
| HLB2008-040S | R0.4 | 4 | 0.64 | 0.77 | 16° | 40 | 4 | 28.0 | 5,520 | 3,312 |
| HLB2008-050S | R0.4 | 5 | 0.64 | 0.77 | 16° | 40 | 4 | 27.0 | 5,520 | 3,312 |
| HLB2008-060S | R0.4 | 6 | 0.64 | 0.77 | 16° | 40 | 4 | 26.0 | 5,520 | 3,312 |
| HLB2010-025S | R0.5 | 2.5 | 0.8 | 0.96 | 16° | 40 | 4 | 29.5 | 4,320 | 2,592 |
| HLB2010-030S | R0.5 | 3 | 0.8 | 0.96 | 16° | 40 | 4 | 29.0 | 4,320 | 2,592 |
| HLB2010-040S | R0.5 | 4 | 0.8 | 0.96 | 16° | 40 | 4 | 28.0 | 4,920 | 2,952 |
| HLB2010-050S | R0.5 | 5 | 0.8 | 0.96 | 16° | 40 | 4 | 27.0 | 4,920 | 2,952 |
| HLB2010-060S | R0.5 | 6 | 0.8 | 0.96 | 16° | 40 | 4 | 26.0 | 5,280 | 3,168 |
| HLB2012-060S | R0.6 | 6 | 0.96 | 1.16 | 16° | 40 | 4 | 27.0 | 7,140 | 4,284 |
| HLB2015-030S | R0.75 | 3 | 1.2 | 1.44 | 16° | 40 | 4 | 30.5 | 5,040 | 3,024 |
| HLB2015-040S | R0.75 | 4 | 1.2 | 1.44 | 16° | 40 | 4 | 29.5 | 5,040 | 3,024 |
| HLB2015-060S | R0.75 | 6 | 1.2 | 1.44 | 16° | 40 | 4 | 27.5 | 5,040 | 3,024 |
| HLB2020-030S | R1 | 3 | 1.6 | 1.94 | 16° | 40 | 4 | 31.0 | 4,320 | 2,592 |
| HLB2020-040S | R1 | 4 | 1.6 | 1.94 | 16° | 40 | 4 | 30.5 | 4,320 | 2,592 |
| HLB2020-060S | R1 | 6 | 1.6 | 1.94 | 16° | 40 | 4 | 28.5 | 4,920 | 2,952 |
| HLB2020-080S | R1 | 8 | 1.6 | 1.94 | 16° | 40 | 4 | 26.5 | 5,280 | 3,168 |
| HLB2020-180S | R1 | 18 | 1.6 | 1.94 | 16° | 50 | 4 | 26.5 | 5,280 | 3,168 |
| HLB2030-060S | R1.5 | 6 | 2.4 | 2.91 | 16° | 40 | 4 | 28.0 | 5,400 | 3,240 |
| HLB2030-080S | R1.5 | 8 | 2.4 | 2.91 | 16° | 40 | 4 | 28.0 | 5,400 | 3,240 |
| HLB2030-100S | R1.5 | 10 | 2.4 | 2.91 | 16° | 40 | 4 | 26.0 | 6,120 | 3,672 |
| HLB2030-120S | R1.5 | 12 | 2.4 | 2.91 | 16° | 45 | 4 | 29.0 | 6,120 | 3,672 |
| HLB2030-140S | R1.5 | 14 | 2.4 | 2.91 | 16° | 45 | 4 | 27.0 | 6,960 | 4,176 |
| HLB2030-160S | R1.5 | 16 | 2.4 | 2.91 | 16° | 50 | 4 | 30.0 | 6,960 | 4,176 |
| HLB2030-200S | R1.5 | 20 | 2.4 | 2.91 | 16° | 50 | 4 | 26.0 | 6,960 | 4,176 |
| HLB2040-100S | R2 | 10 | 3.2 | 3.91 | 16° | 45 | 6 | 29.0 | 5,520 | 3,312 |
| HLB2040-120S | R2 | 12 | 3.2 | 3.91 | 16° | 45 | 6 | 27.0 | 6,240 | 3,744 |
| HLB2050-120S | R2.5 | 12 | 4 | 4.91 | 16° | 45 | 6 | 29.0 | 8,760 | 5,256 |
| HLB2060-150S | R3 | 15 | 4.8 | 5.91 | - | 45 | 6 | 28.0 | 9,240 | 5,544 |
| HLB2060-300S | R3 | 30 | 4.8 | 5.91 | 60 | 6 | 28.0 | 9,240 | 5,544 |
